MC8207 Home Theater Amplifier

MC8207 ELECTRONIC SPECIFICATIONS Power Output per Channel:200W @ 4 or 8 Ohms Number of Channels: – 7 (can also be used as a 2-zone amplifier with 5 channels in zone A and 2 channels in zone B) Total Harmonic Distortion:0.005% S/N below rated output:112dB Dynamic Headroom:1.7dB Damping Factor:>140 Rated Power Band:20Hz to 20kHz Frequency Response: +0, -0.25dB from 20Hz to 20,000Hz +0, -3dB from 10Hz to 100,000Hz CONTROL Remote Power Control: Yes, 7 or 5 + 2 Channel Multi-Channel DB25 Cable: N/A GENERAL SPECIFICATIONS Circuit Configuration: Push-Pull Complementary Circuit Design: Solid State Mono Bridge: No Mono Parallel: No Output Type: – Direct Coupled with Dynamic Power Manager® Meters: Yes, new style LED Meter Light Switch: No Balanced Input: Yes Front Panel: Glass Illumination: LED Fiber Optic Chassis Style: Inverted CONNECTIVITY Speaker Binding Post Type: Yes WEIGHTS & DIMENSIONS Unit Dimensions (W x H x D): – 17-1/2″ (44.5cm) x 9-7/16″ (23.9cm) (including feet) x 21″ (53.3cm) (including front panel and cables) Unit Weight: 83 lbs (37.6 kg) Shipping Weight: 116 lbs (52.6 kg)
